SIEMENS simatic basiseenheid 6ES75121DM030AB0
Artikelnummer: 11007484
Artikelnummer fabrikant: 6ES75121DM030AB0
EAN Code: 4047623412731
Siemens AG, SIMATIC CPU 1512SP-1 PN, CPU 1512SP-1 PN, 400KB Prog., 2M..., SIMATIC ET 200SP CPU 1512SP-1 PN, DC, Schroef-/veerklemaansluiting, ATEX gas-Ex-Beveiliging, Cat. 3G, Geen, IP20
SIMATIC DP, CPU 1512SP-1 PN for ET 200SP, central processing unit with 400 KB work memory for program and 2 MB for data, 1st interface: PROFINET IRT with 3-port switch, 6 ns bit performance, including server module (6ES7193-6PA00-0AA0); SIMATIC Memory Card required, BusAdapter required for port 1 and 2 With SIMATIC ET 200SP, Siemens offers a multifunctional and distributed I/O system, which can be commissioned very simply due to its space-saving design. It is approved for degree of protection IP20 and for installation in a compact control box. The system ensures maximum flexibility because you can quickly and simply replace modules at any time due to the multi hot swapping feature. SIMATIC ET 200SP also offers a wide range of different and fast communication methods. With the integrated MultiFieldbus interface module IM155-6MF, you can use the optimum protocol for your application flexibly at any time because this function supports multiple Ethernet protocols. Installation and service
| Beschermingsgraad (IP) | IP20 |
| Breedte | 100 mm |
| Hoogte | 117 mm |
| Diepte | 75 mm |
| Uitvoering elektrische aansluiting | Schroef-/veerklemaansluiting |
| Geschikt voor veiligheidsfunctie | Nee |
| Explosieveiligheidscategorie voor gas | ATEX gas-Ex-Beveiliging, Cat. 3G |
| Explosieveiligheidscategorie voor stof | Geen |
| Type ingangsspanning | DC |
| Ondersteunt protocol voor LON | Nee |
| Aantal HW-interfaces industrieel ethernet | 1 |
| Aantal HW-interfaces serieel RS-232 | 0 |
| Aantal HW-interfaces serieel RS-422 | 0 |
| Aantal HW-interfaces serieel RS-485 | 1 |
| Aantal HW-interfaces serieel TTY | 0 |
| Aantal HW-interfaces USB | 0 |
| Aantal HW-interfaces parallel | 0 |
| Aantal HW-interfaces overige | 0 |
| Ondersteunt protocol voor ASI | Ja |
| Ondersteunt protocol voor PROFIBUS | Ja |
| Ondersteunt protocol voor CAN | Nee |
| Ondersteunt protocol voor INTERBUS | Nee |
| Ondersteunt protocol voor KNX | Nee |
| Ondersteunt protocol voor MODBUS | Ja |
| Ondersteunt protocol voor Data-Highway | Nee |
| Ondersteunt protocol voor DeviceNet | Nee |
| Ondersteunt protocol voor SUCONET | Nee |
| Ondersteunt protocol voor overige bussystemen | Nee |
| Draagrailmontage mogelijk | Ja |
| Ondersteunt protocol voor SERCOS | Nee |
| Ondersteunt protocol voor INTERBUS-Safety | Nee |
| Aantal interfaces PROFINET | 1 |
| Aantal HW-interfaces Wireless | 0 |
| Frontinbouw mogelijk | Nee |
| Rackmontage mogelijk | Nee |
| Wand-/directmontage mogelijk | Ja |
| Radiostandaard Bluetooth | Nee |
| Radiostandaard WLAN 802.11 | Nee |
| IO-Link Master | Nee |
| Ondersteunt protocol voor AS-Interface Safety at Work | Nee |
| Ondersteunt protocol voor DeviceNet Safety | Nee |
| Ondersteunt protocol voor EtherNet/IP | Nee |
| Ondersteunt protocol voor Foundation Fieldbus | Nee |
| Ondersteunt protocol voor PROFINET CBA | Nee |
| Ondersteunt protocol voor PROFINET IO | Ja |
| Ondersteunt protocol voor PROFIsafe | Nee |
| Ondersteunt protocol voor SafetyBUS p | Nee |
| Radio standaard GPRS | Nee |
| Radio standaard GSM | Nee |
| Radio standaard UMTS | Nee |
| Met optische interface | Ja |
| Veldbusaansluiting via separate buskoppelaar mogelijk | Ja |
| Systeemcomponenten | Ja |
| Bijbehorend bedrijfsmiddel (Ex ia) | Nee |
| Bijbehorend bedrijfsmiddel (Ex ib) | Nee |
| Ondersteunt protocol TCP/IP | Ja |
| Ingangsspanning bij DC | 19.200 - 28.800 V |
| Max. primaire stroom bij DC | 0,7 A |
| Aantal slots | 80 |
| Met inplug-modules, digitale I/O | Ja |
| Met inplug-modules, analoge I/O | Ja |
| Met inplug-modules, communicatiemodules | Ja |
| Met inplug-modules, functie- en technologie-module | Ja |
| Met inplug-modules, centrale modules | Ja |
| Met inplug-modules, overige | Ja |
| Met buskoppelaar voor modulaire stationsopbouw | Ja |
| Model | SIMATIC CPU 1512SP-1 PN |
| Ondersteunt protocol voor EtherCAT | Nee |
