SIEMENS fasebewaking 3UG4618-2CR20
Artikelnummer: 9877935
Artikelnummer fabrikant: 3UG46182CR20
EAN Code: 4011209642614
Siemens AG, SIRIUS 3UG4, FOR 3-PHASE VOLT. WITH N COND., Monitoring relay for 3-ph. voltage with N cond. Phase failure 3x 160-6, AC, Veerklemaansluiting, 90.000 - 400.000, 90.000 - 400.000, AC
!!! product phase-out !!! the preferred successor is 3UG5618-2CR20 phase failure and sequence monitoring 3x 160-690 V, spring-loaded terminal digital monitoring relay for 3-phase voltage with N conductor automatic phase sequence correction phase failure 3 x 90 to 400 V AC 50 to 60 Hz undervoltage and overvoltage 90-400 V hysteresis 1-20 V OFF delay 0-20 s asymmetry 0-20% 1 changeover contact for phase correction 1 changeover contact for power system faults spring-loaded connection system for monitoring phase sequence, phase failure and phase asymmetry as well as undervoltage and overvoltage, e.g. with unstable networks or mobile systems such as A/C compressors, refrigerated containers, construction site compressors or cranes Worldwide use thanks to wide voltage supply range and international certificates. The relay is variably adjustable to overshoot, undershoot or window monitoring. Delay times and RESET behavior are freely parameterizable. Less space required in the control cabinet t
| Breedte | 22,5 mm |
| Hoogte | 103 mm |
| Diepte | 91 mm |
| Uitvoering elektrische aansluiting | Veerklemaansluiting |
| Aantal contacten als verbreekcontact | 0 |
| Aantal contacten als maakcontact | 0 |
| Aantal contacten als wisselcontact | 2 |
| Type stuurspanning | AC |
| Nom. stuurspanning Us bij AC 50HZ | 90.000 - 400.000 V |
| Nom. stuurspanning Us bij AC 60HZ | 90.000 - 400.000 V |
| Spanningstype voedingsspanning | AC |
| Nom. (meet)schakelstroom | 3 |
| Met afneembare klemmen | Ja |
| Max. toegestane afvalvertragingstijd | 20 s |
| Min. instelbare afvalvertragingstijd | 0,1 s |
| Spanningsmeetbereik | 90.000 - 400.000 V |
| Fasevolgordebewakingsfunctie | Ja |
| Fase-uitvalfunctie | Ja |
| Functie onderspanningsdetectie | Ja |
| Functie overspanningsdetectie | Ja |
| Fase-onbalansfunctie | Ja |
| Voedingsspanning bij AC 50Hz | 90.000 - 400.000 |
| Voedingsspanning bij AC 60Hz | 90.000 - 400.000 |
| Model | SIRIUS 3UG4 |
